High value one-stop service from layout to assembly– DISHA Elektronics

Disha Elektronics is PCB manufacturer which specialized in quick turn prototype and mass production .

Rigid PCB from 1 layer to 28 layers, FPCB from 1 layer to 4 layers. We trust the high quality,
the competitive price and the excellent service will be sure to meet your demands.

Our Process

HDI PCB

Base Material: FR4,
Min.Board thickness: 2.4mm
Copper thickness: 1oz-6oz
Surface finished: ENIG
Min.Hole size: 0.2mm
Min.line Width and Spacing: 0.1mm

Single/double side PCB

Base Material: FR4, Aluminum, CEM1, CEM-3, 94V0, 94HB
Min.Board thickness: 0.2mm
Copper thickness: 1oz-6oz
Surface finished: ENIG, ImAg, ImSn, OSP, HASL, Plating gold
Min.Hole size: 0.2mm
Min.line Width and Spacing: 0.1mm

Multilayer board

Layer: 4-12L
Base Material: FR4(TG135,TG150,TG170,TG180), BT
Min.Board thickness: 0.4mm
Max.Copper thickness: Outer 6OZ,Inner 4OZ
Surface finished: ENIG, ImAg, ImSn, OSP, HASL, Plating gold
Min.Hole size: 0.2mm
Min.line Width and Spacing: 0.1mm

FPC

Layer:1-4L
Base material:Polyimide and polyester
Min.Board thickness:0.1mm
Copper thickness: 17um-105um
Surface finished:ENIG, Plated gold,OSP
Min.hole size:0.1mm
Min.trace width/space:0.07mm
